1/2 "2sn Hydraulic Hose
video

1/2 "2sn Hydraulic Hose

Lub npe: 1/2 "2sn hydraulic hoseTube: Roj resistant hluavtaws roj hmabReinforcement: ob lub siab tensile steel hlau txheej 2 wCover: Abrasion thiab huab cua resistant hluavtaws roj hmab kub ntau yam: -40℃rau +100 degree
Xa kev nug
Khoom Taw qhia

Specifications rau hydraulic hoses

1. Roj & huab cua resistant roj hmab

2.Steel hlau braided los yog kauv

3. Kev kub siab, zoo yoog raws

4.SAE & DIN & EN tus qauv

Lub hydraulic hose yog siv nyob txhua qhov chaw hauv hydraulic system xav tau kev sib txuas yooj yim ntawm ob qhov chaw nres nkoj dej. Lub hydraulic hose yog ib lub raj roj hmab hluavtaws uas nyob ib puag ncig los ntawm qee yam kev hloov pauv lub zog ua kom muaj zog winding, xws li hlau lossis fiber ntau, thiab tom qab ntawd them rau lwm cov roj hmab carcass.


Txhawm rau qhuas peb cov khoom siv hose, xaiv los ntawm ntau yam khoom siv, xws li hlau, tooj dag, thiab stainless hlau hydraulic adapters thiab cais cov khoom siv flange. Txhawm rau txhim kho lub neej ntawm lub hose thiab kev ua tau zoo peb muaj lub caij nplooj ntoos hlav tiv thaiv, lub tsho nylon hose, thiab kauv - lub tsho tiv thaiv hose. Cov khoom no yog tsim los ntawm tib qhov chaw raws li qhov loj tshaj plaws hose raug npe ntawm tus nqi tseem ceeb txuag.


SAE 100 R2 AT DIN EN 853 2SN Hlau Hlau Braided Hydraulic Hose
Hose Loj (Inch)
Hose Loj (mm)
HOM OD (mm)
Max. Ua Haujlwm Siab
Kev kub ntxhov
3/16
5
14
415 Bar / 6000 Psi
1660 Bar / 24000 / Psi
1/4
6
15
400 Bar / 5800 Psi
1600 Bar / 23200 Psi
5/16
8
15.5
350 Bar / 5000 Psi
1440 Bar / 20000 Psi
3/8
10
19
330 Bar / 4800 Psi
1320 Bar / 19200 Psi
1/2
12
22
275 Bar / 4000 Psi
1100 Bar / 16000 Psi
5/8
16
26
250 Bar / 3600 Psi
1000 Bar / 14400 Psi
3/4
19
29
215 Bar / 3100 Psi
860Bar/12400Psi
1
25
36
165 Bar / 2400 Psi
640 Bar / 9600 Psi
1-1/4
32
45
125 Bar / 1800 Psi
500 Bar / 7200 Psi
1-1/2
38
51
90 Bar / 1300 Psi
360 Bar / 5200 Psi
2
50
65
80 Bar / 1160 Psi
320 Bar / 4640 Psi

1/2 nti DIN EN853 2SN muaj hloov tau hydraulic roj hmab hose

Nta:

1.Nws muab cov roj ua haujlwm zoo dua, tiv thaiv tshav kub thiab kev laus ua haujlwm.

2.Nws muab kev kub siab tsis kam thiab superior impulse kuj.

3.Nws muab kev sib txuas zoo dua hauv hose sab hauv, siv mos thiab me me deformation nyob rau hauv siab.

Daim ntawv thov:

Feem ntau siv rau hauv kuv qhov kev txhawb nqa hydraulic, kev tshawb nrhiav roj, haum rau kev tsim kho engineering, crane thauj,

forging metallurgy, cov khoom siv mining, nkoj, kev txhaj tshuaj molding machinery, kev ua liaj ua teb machinery ntau yam

tshuab cuab yeej.


Cim npe nrov: 1/2 "2sn hydraulic hose, Tuam Tshoj, lwm tus neeg, manufacturers, hoobkas, qis nqi
