1/2 Nti Hydraulic Hose
steel hlau reinforced hydraulic hoseyog tsim rau xa roj av-raws li hydraulic roj ua tsaug rau nws cov roj resistant raj. Tsis tas li ntawd, nws tuaj yeem xa cov roj yam tsis muaj hluav taws xob ntau dhau thiab xau. Nws yog siv rau hauv qee yam khoom siv txawb, xws li tsheb laij teb ua liaj ua teb, tsheb thauj khoom pov tseg thiab hauv - cov khoom siv hydraulic cog. Nws yog tsim los ntawm peb qhov chaw: raj, kev txhawb zog thiab npog. Lub raj yog tsim los ntawm cov roj resistant hluavtaws roj hmab, yog li nws yog siv los hloov cov roj. Qhov cuab lub zog yog tsim los ntawm ob txheej ntawm high tensile braided steel hlau, ua rau cov hose muaj cov qauv ruaj khov thiab tiv taus siab. Yog li ntawd, nws muaj kev ua tau zoo hauv kev ua haujlwm siab ua haujlwm.
steel hlau reinforced hydraulic hose:
Structure: nws yog tsim los ntawm peb qhov chaw: raj, reinforcement thiab npog.
Tube: siab zoo hluavtaws roj hmab, ua lub hose resistant rau abrasion, corrosion thiab roj.
Kev txhawb zog: ob txheej ntawm high tensile braided steel hlau, ua rau lub hose muaj kev ua tau zoo hauv kev ua haujlwm siab.
Npog: zoo zoo hluavtaws roj hmab, ua lub hose resistant rau abrasion, corrosion, txiav, laus, huab cua thiab ozone.
Ua haujlwm kub: -40℃rau +100℃.
Cov lus qhia ntawm EN 856 4SP steel hlau spiraled hydraulic hose (1)
| Hose code | Loj | Dash loj | ID | OD | |||||
| mm | nti | min | min | min | |||||
| TS EN 8564SP-01 | 6.3 | 1/4 | -4 | 6.2 | 7 | 14.1 | 15.3 | 17.1 | 18.7 |
| TS EN 8564SP-02 | 10 | 3/8 | -6 | 9.3 | 10.1 | 16.9 | 18.1 | 20.6 | 22.2 |
| TS EN 8564SP-03 | 12.5 | 1/2 | -8 | 12.3 | 13.5 | 19.4 | 21 | 23.8 | 25.4 |
| TS EN 8564SP-04 | 16 | 5/8 | -10 | 15.5 | 16.7 | 23 | 24.6 | 27.4 | 29 |
| TS EN 8564SP-05 | 19 | 3/4 | -12 | 18.6 | 19.8 | 27.4 | 29 | 31.4 | 33 |
| TS EN 8564SP-06 | 25 | 1 | -16 | 25 | 26.4 | 34.5 | 36.1 | 38.5 | 40.9 |
| TS EN 8564SP-07 | 31.5 | 1-1/4 | -20 | 31.4 | 33 | 45 | 47 | 49.2 | 52.4 |
| TS EN 8564SP-08 | 38 | 1-1/2 | -24 | 37.7 | 39.3 | 51.4 | 53.4 | 55.6 | 58.8 |
| TS EN 8564SP-09 | 51 | 2 | -32 | 50.4 | 52 | 64.3 | 66.3 | 68.2 | 71.4 |
Cov lus qhia ntawm EN 856 4SP steel hlau spiraled hydraulic hose (2)
| Hose code | Ua hauj lwm siab | Pov thawj siab | Min tawg siab | Min khoov vojvoog | Qhov hnyav | |||
| psi | psi | psi | mm | kg/m | ||||
| TS EN 8564SP-01 | 45 | 6525 | 90 | 13050 | 180 | 26100 | 150 | 0.64 |
| TS EN 8564SP-02 | 44.5 | 6450 | 89 | 12905 | 178 | 25810 | 180 | 0.75 |
| TS EN 8564SP-03 | 41.5 | 6020 | 83 | 12035 | 166 | 24070 | 230 | 0.89 |
| TS EN 8564SP-04 | 35 | 5075 | 70 | 10150 | 140 | 20300 | 250 | 1.1 |
| TS EN 8564SP-05 | 35 | 5075 | 70 | 10150 | 140 | 20300 | 300 | 1.5 |
| TS EN 8564SP-06 | 28 | 4060 | 56 | 8120 | 112 | 16240 | 340 | 2 |
| TS EN 8564SP-07 | 21 | 3045 | 42 | 6090 | 84 | 12180 | 460 | 3 |
| TS EN 8564SP-08 | 18.5 | 2680 | 37 | 5365 | 74 | 10730 | 560 | 3.4 |
| TS EN 8564SP-09 | 16.5 | 2390 | 33 | 4785 | 66 | 9570 | 660 | 4.35 |
Cim npe nrov: 1/2 nti hydraulic hose, Tuam Tshoj, lwm tus neeg, manufacturers, hoobkas, qis nqi
